Automatic Closed Cup Flash Point Tester Pensky-Martins Oil Flash Point Testing Instrument

Name: Automatic Closed Cup Flash Point Tester PenskyMartins Oil Flash Point Testing Instrument
Brand: MINGYANG
Price: 1400 USD

Wholesale Automatic Closed Cup Flash Point Tester Pensky-Martins Oil Flash Point Testing Instrument from china suppliers

Price : 1400usd

Packaging Details : carton

Power : 2000

Test current : DC 20A ~120A

Cooling Method : Forced Air Cooling

Model Number : MY 201

Accuracy Class : Standard Accuracy

Detection type : open flash point or ignition point

Brand Name : MINGYANG

Type : Closed Cup Flash Point Tester

Standard : Comply with GB3536-2008 (ASTM D92), GB/T 267-88

Supply Ability : 1000pcs/month

Power supply : 220V 50Hz

Voltage : 220 V

Power Supply : AC 220V±10%

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Place of origin : Hubei, China

Resolution : 0.1 ℃

Delivery Time : 1 week

Weight : 5KG

Customized support : OEM, ODM, OBM

Work rate : ≤350VA

Ignition Method : Electrical Ignition

Place of Origin : China Mainland

Application : Auto Testing

MOQ : 1

Warranty : 2 years

Information storage : 1000 measurement results can be stored

Measuring range : room temperature~350℃

The use of temperature : -10°c~40°c

Contact Now

Automatic Closed Cup Flash Point Tester Pensky-Martins Oil Flash Point Testing Instrument

Advanced automatic closed cup flash point testing equipment designed for precise determination of flash points in petroleum products and oils using the Pensky-Martens method.

Basic Info.

Model NO.

MY 201

Repeatability

0.5%

Resolution

0.1

Accuracy

0.5%

Temperature Sensor

Platinum Resistance (PT100)

Flash Fire Sensor

Ion Detection Ring

Environmental Temperature

10-40

Relative Humidity

<85%

Power

<500W

Heating Rate

in Line with GB, Us, and EU Standards

Transport Package

Wooden Case or Carton

Specification

see details

Trademark

YANGMING

Origin

China

HS Code

9030849000

Production Capacity

200 Sets Per Month

Product Description

Product overview
UHV-650 Automatic closed flash point measuring device, with a touch screen replace the keyboard. It can detect the closed flash point value of petroleum products. Adopts foreign advanced technology, the large-screen LCD display, it is prompted to enter by full-screen touch buttons; it is convenient, open, fuzzy control integration software, modular structure, in line with the national standard, the United States, and the European Union standards. Widely used in railway, aviation, electricity, petroleum industry and scientific research departments

Products features
1 Using new high-speed digital signal processor, high precision and reliable
2 Detection, uncap, ignition, alarm, cooling, print, all tests finished automatically
3 Platinum heating wire (standard), gas ignition (optional)
4 Automatic detect atmospheric pressure, automatic correct test results
5 Using the newly developed high-power high-frequency switching power supply heating technology, high heating efficiency, the use of adaptive PID control algorithm automatically adjusts the heating curve
6 Automatic stop detection and to alarm when exceed temperature range
7 Thermal mini-printers, with offline printing function
8 Historical records with time marks, store up to 255 groups
9 The calendar clock with temperature compensation, time accurate, automatically records the date and time of measurement, under power-down state can run more than 10 years
10 Using 320x240 large-screen graphical LCD display
11 Touch screen buttons, easy to operate and intuitive
12 Built-in many of implementation standards to select

Technical Specifications

Display	Color LCD display
Operating Mode	Touch Screen
Measuring Range	Room temperature ~ 350℃
Temperature Detection	Platinum sensor
Repeatability	>110℃ ±2℃; ≤110℃ ±1℃
Ignition Method	Electric ignition
Information Storage	Can store 1000 analysis results
Cooling Method	Forced air cooling
Printer	Thermal printer
Standards Compliance	ASTM D93, GB/T 261 standards
Power Supply	AC 220V ±11V, 50Hz ±2.5Hz
Power Consumption	≤350VA
Operating Temperature	10℃ ~ 35℃
Operating Humidity	≤85%
